QED121
RoHS
/
Package Radial, 5mm Dia (T 1 3/4)
Category Optoelectronics / Infrared, UV, Visible Emitters
Description
LED IrLED 890nm 2-Pin T-1 3/4 Bulk
PDF
/
Buying Options
Total Price: USD $4.59
Unit Price: USD $4.588642
≥1 USD $4.588642
≥10 USD $4.328904
≥100 USD $4.083872
≥500 USD $3.852704
≥1000 USD $3.634631
Inventory: 1189
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Radiant Intensity (Ie) Min @ If 16mW/sr @ 100mA
Reverse Voltage-Max 5V
Current - DC Forward (If) (Max) 100mA
Wavelength 880nm
Forward Current-Max 0.1A
Size 4.95mm
Lens Style Circular
Viewing Angle 18°
Configuration SINGLE
Operating Supply Voltage 1.7V
Number of Functions 1
Orientation Top View
Power Rating 200mW
Type Infrared (IR)
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Packaging Bulk
Operating Temperature -40°C~100°C TA
Physical
Semiconductor Material AlGaAs
Shape ROUND
Weight 284.4mg
Number of Pins 2
Package / Case Radial, 5mm Dia (T 1 3/4)
Mounting Type Through Hole
Mount Through Hole
