EAISV1608A1
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / Infrared, UV, Visible Emitters
Description
EMITTER IR 850NM 65MA
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.695837
≥1 USD $0.695837
≥200 USD $0.278335
≥500 USD $0.269145
≥1000 USD $0.263893
Inventory: 6699
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Radiant Intensity (Ie) Min @ If 2mW/sr @ 20mA
Touchscreen Infrared (IR)
Current - DC Forward (If) (Max) 65mA
Wavelength 850nm
Forward Current-Max 0.065A
Size 1.6mm
Viewing Angle 40°
Voltage - Forward (Vf) (Typ) 1.4V
Configuration SINGLE
Number of Functions 1
Orientation Side View
HTS Code 8541.40.20.00
Type Infrared (IR)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C TA
Physical
Shape RECTANGULAR
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
