EAIST1608A1
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / Infrared, UV, Visible Emitters
Description
EMITTER IR 875NM 65MA
PDF
/
Inventory: 6728
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Shape RECTANGULAR
Technical
Operating Temperature -25°C~85°C TA
Packaging Tape & Reel (TR)
Published 2014
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type Infrared (IR)
HTS Code 8541.40.20.00
Orientation Top View
Number of Functions 1
Configuration SINGLE
Voltage - Forward (Vf) (Typ) 1.3V
Viewing Angle 145°
Size 1.2mm
Forward Current-Max 0.065A
Wavelength 875nm
Current - DC Forward (If) (Max) 65mA
Touchscreen Infrared (IR)
Radiant Intensity (Ie) Min @ If 0.2mW/sr @ 20mA
Compliance
RoHS Status ROHS3 Compliant
