MT9V024IA7XTM-DR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Image Sensors, Camera
Description
Image Sensor Monochrome CMOS 752x480Pixels 52-Pin IBGA Dry Pack
PDF
/
Buying Options
Total Price: USD $22.82
Unit Price: USD $22.8209
≥1 USD $22.8209
≥10 USD $18.72545
≥100 USD $18.14025
≥500 USD $17.55505
≥1000 USD $16.96985
Inventory: 8409
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1.3mm
Technical
Array Type FRAME
Vertical Pixel 480
Frame Rate 60 fps
Master Clock 27 MHz
Horizontal Pixel Count 752
Optical Format 1/3 inch
Dynamic Range 100 dB
Pixel Size 6x6μm
Output Interface Type 2-WIRE INTERFACE
Output Range 0.30-3V
Sensors/Transducers Type IMAGE SENSOR,CMOS
Termination Type SOLDER
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Output Type DIGITAL VOLTAGE
Body Breadth 9 mm
Body Length or Diameter 9mm
Additional Feature GLOBAL SHUTTER
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Published 2013
Physical
Number of Pins 52
Mount Surface Mount
Contact Plating Copper, Silver, Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 17 Weeks
