MT9T031C12STC-DR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Image Sensors, Camera
Description
2-WIRE INTERFACE ELECTRONIC ROLLING SHUTTER IT ALSO OPERATES AT ANALOG SUPPLY VOLTAGE 3-3.60V SURFACE MOUNT Active (Type) Image Sensor 14.22mm 27.8mA 3.6V 61dB
PDF
/
Buying Options
Total Price: USD $42.57
Unit Price: USD $42.56947
≥1 USD $42.56947
≥200 USD $16.474269
≥500 USD $15.89528
≥1000 USD $15.609068
Inventory: 9456
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Additional Feature ELECTRONIC ROLLING SHUTTER, IT ALSO OPERATES AT ANALOG SUPPLY VOLTAGE 3-3.60 V
Body Length or Diameter 14.22mm
Body Breadth 14.22 mm
Output Type DIGITAL VOLTAGE
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Termination Type SOLDER
Sensors/Transducers Type IMAGE SENSOR,CMOS
Housing CERAMIC
Output Range 0.30-3.30V
Output Interface Type 2-WIRE INTERFACE
Pixel Size 3.20x3.20μm
Operating Current-Max 27.8mA
Dynamic Range 61 dB
Optical Format 1/2 inch
Horizontal Pixel Count 2048
Master Clock 48 MHz
Frame Rate 12 fps
Vertical Pixel 1536
Array Type FRAME
Dimensions
Body Height 2.25mm
Compliance
RoHS Status ROHS3 Compliant
