MT9M024IA3XTC-DPBR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Image Sensors, Camera
Description
SENSOR IMAGE 1.6MP CMOS 48-LCC
PDF
/
Buying Options
Total Price: USD $36.57
Unit Price: USD $36.572142
≥1 USD $36.572142
≥260 USD $14.153062
≥520 USD $13.655473
≥1040 USD $13.409961
Inventory: 2740
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
Published 2015
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature ELECTRONIC ROLLING SHUTTER, IT ALSO OPERATES AT 2.50-3.10 V ANALOG SUPPLY VOLATGE
Body Length or Diameter 9mm
Operating Temperature (Max) 70°C
Body Breadth 9 mm
Operating Temperature (Min) -30°C
Output Type DIGITAL VOLTAGE
Supply Voltage-Max (Vsup) 1.95V
Supply Voltage-Min (Vsup) 1.7V
Termination Type SOLDER
Sensors/Transducers Type IMAGE SENSOR,CMOS
Output Range 0.40-1.50V
Output Interface Type 2-WIRE INTERFACE
Pixel Size 3.75μm
Operating Current-Max 130mA
Dynamic Range 120 dB
Optical Format 1/3 inch
Horizontal Pixel Count 1280
Master Clock 50 MHz
Frame Rate 45 fps
Vertical Pixel 960
Array Type SINGLE FRAME
Dimensions
Body Height 1.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
