ODC5A
RoHS
/
Package Module
Category Relays / I/O Relay Modules
Description
RoHS Compliant Red Lead Free CE CSA UL DC Output Module -30C 0.75ms 43.2mm 18mA
PDF
/
Buying Options
Total Price: USD $44.18
Unit Price: USD $44.184584
≥1 USD $44.184584
≥10 USD $41.683573
≥100 USD $39.324122
≥500 USD $37.098223
≥1000 USD $34.998336
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 15.2mm
Length 43.2mm
Height 31.8mm
Technical
Current - Input 18mA
Nominal Input Voltage (DC) 5V
Turn Off Time 0.75ms
Max Input Voltage (DC) 8V
Turn On Time 0.10ms
Turn-Off Delay Time 750 μs
Voltage - Output 3V~250VDC
Turn On Delay Time 100 μs
Voltage - Input 5VDC
Number of Channels 2
Operating Supply Voltage 5V
Output Type Digital
Approval Agency CE, CSA, UL
Current Rating 1A
Style Standard
Depth 31.8mm
Color Red
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Type DC Output Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Hold Down Screw
Series ODC
Published 2001
Physical
Package / Case Module
Mount PCB, Plug-In, Through Hole
Supply Chain
Factory Lead Time 5 Weeks
