OAC5
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Relays / I/O Relay Modules
Description
PC Pins Bulk RoHS Compliant Black AC Output Module -30C 8.33ms 31.8mm 20mA
PDF
/
Buying Options
Total Price: USD $34.01
Unit Price: USD $34.012
≥1 USD $34.012
Inventory: 88
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 43.2mm
Length 31.8mm
Height 31.7mm
Technical
Current - Input 20mA
Nominal Input Voltage (DC) 5V
Turn Off Time 8.33ms
Max Input Voltage (DC) 8V
Load Current 2.5mA
Turn On Time 8.33ms
Max Input Current 20mA
Turn-Off Delay Time 8.33 ms
Voltage - Output 12V~140VAC
Turn On Delay Time 8.33 ms
Throw Configuration SPST
Current - Output 3.5A
Voltage - Input 5VDC
Number of Channels 1
Operating Supply Voltage 5V
Max Output Current 3.5A
Approval Agency CE, CSA, UL
Number of Outputs 1
Current Rating 20A
Style Standard
Depth 31.8mm
Voltage - Rated DC 5V
Color Black
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Type AC Output Module
Termination PC Pins
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Hold Down Screw
Series OAC
Published 2010
Packaging Bulk
Physical
Weight 31.2g
Package / Case Module
Mount PCB, Plug-In, Through Hole
Supply Chain
Factory Lead Time 6 Weeks
