70M-ODC5B
RoHS
/
Package Module
Category Relays / I/O Relay Modules
Description
OUTPUT MODULE DC MINI 14MA 5VDC
PDF
/
Buying Options
Total Price: USD $15.07
Unit Price: USD $15.0744
≥1 USD $15.0744
≥10 USD $13.40328
≥100 USD $12.732896
≥500 USD $12.062864
≥1000 USD $11.392656
≥3000 USD $10.387414
Inventory: 306
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Screw, Through Hole
Package / Case Module
Number of Pins 5
Technical
Published 2003
Series 70
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Type DC Output Module
Resistance 300Ohm
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Voltage - Rated DC 60V
Depth 10.16mm
Style Mini
Current Rating 3A
Approval Agency CE, CSA, TUV, UL
Output Type Digital
Number of Channels 1
Voltage - Input 5VDC
Current - Output 3A
Number of Poles 1
Throw Configuration SPST
Turn On Delay Time 75 μs
Voltage - Output 3V~60VDC
Min Input Voltage 2.5V
Max Input Voltage 10V
Turn-Off Delay Time 500 μs
Turn On Time 0.075ms
Load Current 3A
Max Input Voltage (DC) 60V
Turn Off Time 0.50ms
Current - Input 14mA
Dimensions
Height 25.4mm
Length 43.18mm
Width 25.4mm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
