CRF05-1A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / High Frequency (RF) Relays
Description
STANDEXMEDER CRF05-1A Reed Relay, CRF Series, 5 VDC, 150 ohm, 500 mA, 170 V, SPST-NO
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 7560
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Number of Pins 10
Weight 370mg
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2004
Series CRF
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
HTS Code 8536.49.00.50
Depth 4.4mm
Termination Style SMD (SMT) Tab
Physical Dimension 8.6mm x 4.4mm x 3.55mm
Contact Resistance 250mOhm
Insulation Resistance 10 TΩ
Contact Current(DC)-Max 0.5A
Sealing WATER PROOF
Contact Voltage(DC)-Max 170V
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Relay Type RF
Contact Current(AC)-Max 0.5A
Coil Resistance 150Ohm
Contact (AC) Max Rating R Load .5A@170VAC
Operate Time 0.1ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 170VAC 170VDC -Max
Coil Current 33.3mA
Release Time 0.02ms
Contact (DC) Max Rating R Load .5A@170VDC
Must Operate Voltage 3.75VDC
Coil Power 167mW
Must Release Voltage 0.75VDC
Operating Frequency-Max 7000MHz
Contact Voltage(AC)-Max 170V
Contact/Output Supply Type AC/DC
Relay Action MOMENTARY
Coil Voltage (DC) 5V
Coil/Input Supply Type DC
Switching Current 500mA
Dimensions
Length 8.6mm
Width 4.4mm
Body Height 3.55mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
