ARE13A12ZC90
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / High Frequency (RF) Relays
Description
ROHS3Compliant Non Latching Surface Mount SPDT (1Form C) High Frequency Relay 200mW -40C~70C 12VDC 720Ohm
PDF
/
Inventory: 2195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Must Release Voltage 1.2VDC
Coil Power 200mW
Contact Rating (Current) 500mA
Must Operate Voltage 9VDC
Release Time 5ms
Coil Current 16.7mA
Switching Voltage 30VDC -Max
Coil Type Non Latching
Coil Voltage 12VDC
Operate Time 10ms
Coil Resistance 720Ohm
Contact Form SPDT (1 Form C)
Termination Style Gull Wing
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Part Status Active
Series ARE
Packaging Tape & Reel (TR)
Operating Temperature -40°C~70°C
Physical
Mounting Type Surface Mount
Contact Material Gold Plating
Supply Chain
Factory Lead Time 12 Weeks
