ARE1309C90
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / High Frequency (RF) Relays
Description
ROHS3Compliant Non Latching Through Hole SPDT (1Form C) High Frequency Relay 200mW -40C~70C 9VDC 405Ohm
PDF
/
Inventory: 2215
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Gold Plating
Mounting Type Through Hole
Technical
Operating Temperature -40°C~70°C
Series ARE
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Style PC Pin
Contact Form SPDT (1 Form C)
Coil Resistance 405Ohm
Operate Time 10ms
Coil Voltage 9VDC
Coil Type Non Latching
Switching Voltage 30VDC -Max
Coil Current 22.2mA
Release Time 5ms
Must Operate Voltage 6.75VDC
Contact Rating (Current) 500mA
Coil Power 200mW
Must Release Voltage 0.9VDC
Compliance
RoHS Status ROHS3 Compliant
