ARE10A12C90
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / High Frequency (RF) Relays
Description
ROHS3Compliant Non Latching Surface Mount SPDT (1Form C) High Frequency Relay 200mW -40C~70C 12VDC 720Ohm
PDF
/
Inventory: 4183
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Gold Plating
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~70°C
Series ARE
Part Status Active
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Termination Style Gull Wing
Contact Form SPDT (1 Form C)
Coil Resistance 720Ohm
Operate Time 10ms
Coil Voltage 12VDC
Coil Type Non Latching
Switching Voltage 30VDC -Max
Coil Current 16.7mA
Release Time 5ms
Must Operate Voltage 9VDC
Contact Rating (Current) 500mA
Coil Power 200mW
Must Release Voltage 1.2VDC
Compliance
RoHS Status ROHS3 Compliant
