ARE104HC90
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / High Frequency (RF) Relays
Description
ROHS3Compliant Non Latching Through Hole SPDT (1Form C) High Frequency Relay 200mW -40C~70C 4.5VDC 101Ohm
PDF
/
Inventory: 5245
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Must Release Voltage 0.45VDC
Coil Power 200mW
Contact Rating (Current) 500mA
Must Operate Voltage 3.38VDC
Release Time 5ms
Coil Current 44.4mA
Switching Voltage 30VDC -Max
Coil Type Non Latching
Coil Voltage 4.5VDC
Operate Time 10ms
Coil Resistance 101Ohm
Contact Form SPDT (1 Form C)
Termination Style PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ARE
Operating Temperature -40°C~70°C
Physical
Mounting Type Through Hole
Contact Material Gold Plating
Supply Chain
Factory Lead Time 12 Weeks
