G6Z-1FE DC3
RoHS
/
Package /
Category Relays / High Frequency (RF) Relays
Description
Non Latching Surface Mount Sealed - Fully SPDT (1Form C) High Frequency Relay 200mW -40C~70C 3VDC 45Ohms
PDF
/
Inventory: 2343
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper (Cu), Gold (Au)
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~70°C
Packaging Tube
Published 2007
Series G6Z
Feature Sealed - Fully
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Style Gull Wing
Contact Form SPDT (1 Form C)
Coil Resistance 45Ohms
Operate Time 10ms
Coil Voltage 3VDC
Coil Type Non Latching
Switching Voltage 30VAC 30VDC -Max
Coil Current 66.7mA
Release Time 10ms
Must Operate Voltage 2.25VDC
Contact Rating (Current) 10mA
Coil Power 200mW
Must Release Voltage 0.3VDC
