9852-05-10
RoHS
/
Package SMD/SMT
Category Relays / High Frequency (RF) Relays
Description
COTO TECHNOLOGY 9852-05-10 Reed Relay, SPDT, 5 VDC, SMD, 110 ohm, 100 mA
PDF
/
Inventory: 4836
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material Ruthenium
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Number of Pins 8
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2010
Series 9800
JESD-609 Code e4
Feature Magnetic Shield
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Gold (Au)
Additional Feature SHIELDED
Packing Method TAPE AND REEL
Termination Style Axial
Lead Pitch 1.02mm
Physical Dimension 10.16mm x 4.95mm x 4.95mm
Contact Resistance 150mOhm
Insulation Resistance 1GOhm
Row Spacing 12.06 mm
Contact Current(DC)-Max 0.1A
Sealing HERMETICALLY SEALED
Contact Voltage(DC)-Max 30V
Electrical Life 100000000 Cycle(s)
Throw Configuration SPDT
Contact Form SPDT (1 Form C)
Rise Time 260 μs
Relay Type RF
Contact Current(AC)-Max 0.1A
Coil Resistance 110Ohm
Contact (AC) Max Rating R Load .1A@30VAC
Operate Time 1ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 30VAC 30VDC -Max
Coil Current 45.5mA
Release Time 1 ms
Contact (DC) Max Rating R Load .1A@30VDC
Must Operate Voltage 3.8VDC
Coil Power 225mW
Must Release Voltage 0.4VDC
Contact Voltage(AC)-Max 30V
Contact/Output Supply Type AC/DC
Relay Action MOMENTARY
Coil Voltage (DC) 5V
Coil/Input Supply Type DC
Dielectric Strength Between Open Contacts 200 Vrms
Input Switching Control Type Random
Dielectric Strength Between Coil and Contacts 1000 Vrms
Switching Current 100mA
Dimensions
Height 4.95mm
Length 9.52mm
Width 10.16mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
