9402-05-00
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Relays / High Frequency (RF) Relays
Description
REED RELAY, SPST-NO, 5VDC, 0.5A, SMD
PDF
/
Buying Options
Total Price: USD $9.92
Unit Price: USD $9.9176
≥1 USD $9.9176
≥10 USD $9.29896
≥100 USD $8.265664
≥500 USD $7.852592
≥1000 USD $7.439256
≥3000 USD $6.612672
Inventory: 1157
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Material Ruthenium
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2006
Series 9400
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 6
Termination Gull Wing
ECCN Code EAR99
Terminal Finish Gold (Au)
Termination Style Gull Wing
Physical Dimension 14mm x 5.71mm x 5.72mm
Contact Resistance 150mOhm
Insulation Resistance 1000000000000Ohm
Contact Current(DC)-Max 0.5A
Sealing HERMETICAL
Contact Voltage(DC)-Max 200V
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Rise Time 400 μs
Relay Type RF
Contact Current(AC)-Max 0.5A
Coil Resistance 200Ohm
Contact (AC) Max Rating R Load 0.5A@200VAC
Operate Time 0.4ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 200VAC 200VDC -Max
Coil Current 25mA
Release Time 0.2ms
Contact (DC) Max Rating R Load 0.5A@200VDC
Must Operate Voltage 3.75VDC
Must Release Voltage 0.4VDC
Contact Voltage(AC)-Max 200V
Contact/Output Supply Type AC/DC
Relay Action LATCHED
Coil Voltage (DC) 5V
Coil/Input Supply Type DC
Coil Voltage (AC) 5V
Dielectric Strength Between Open Contacts 300 Vrms
Input Switching Control Type Random
Dielectric Strength Between Coil and Contacts 1500 Vrms
Switching Current 500mA
Contact (DC) Max Power Rating R Load 10W@200VDC
Dimensions
Height 5.72mm
Length 17.8mm
Width 5.71mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
