9002-05-01
RoHS
RoHS compliant
RoHS compliantPackage SIP
Category Relays / High Frequency (RF) Relays
Description
RELAY RF SPST 500MA 5V
PDF
/
Buying Options
Total Price: USD $6.59
Unit Price: USD $6.5912
≥1 USD $6.5912
≥10 USD $6.17936
≥100 USD $5.492608
≥500 USD $5.218224
≥1000 USD $4.943488
≥3000 USD $4.394227
Inventory: 3862
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Contact Material Ruthenium
Mount Through Hole
Mounting Type Through Hole
Package / Case SIP
Number of Pins 6
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2003
Series 9000
JESD-609 Code e3
Feature Diode
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination PC Pin
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Reference Standard CSA; UL
Termination Style PC Pin
Approval Agency CSA, UL
Body Length or Diameter 19.3mm
Contact Resistance 125mOhm
Insulation Resistance 1 TΩ
Contact Current(DC)-Max 0.5A
Sealing HERMETICAL
Contact Voltage(DC)-Max 200V
Electrical Life 1000000000 Cycle(s)
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Rise Time 350 μs
Relay Type RF
Contact Current(AC)-Max 0.5A
Coil Resistance 350Ohm
Contact (AC) Max Rating R Load 0.5A@200VAC
Operate Time 0.35ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 200VAC 200VDC -Max
Coil Current 14.3mA
Release Time 0.1ms
Contact (DC) Max Rating R Load 0.5A@200VDC
Must Operate Voltage 3.75VDC
Must Release Voltage 0.4VDC
Contact Voltage(AC)-Max 200V
Contact/Output Supply Type AC/DC
Relay Action LATCHED
Coil Voltage (DC) 5V
Coil/Input Supply Type DC
PCB Hole Count 6
Dielectric Strength Between Open Contacts 300 Vrms
Input Switching Control Type Random
Dielectric Strength Between Coil and Contacts 1500 Vrms
Switching Current 500mA
Contact (DC) Max Power Rating R Load 10W@200VDC
Dimensions
Height 7.6mm
Width 5.08mm
Length - Termination 0.0034 inch
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
