2341-12-020
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / High Frequency (RF) Relays
Description
RELAY RF SPDT 500MA 12V
PDF
/
Buying Options
Total Price: USD $17.78
Unit Price: USD $17.776
≥1 USD $17.776
≥10 USD $16.8872
≥100 USD $15.9984
≥500 USD $15.1096
≥1000 USD $14.2208
≥3000 USD $13.332
Inventory: 1114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 5
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2005
Series 2300
JESD-609 Code e3
Feature Sealed - Hermetically
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination PC Pin
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Termination Style PC Pin
Contact Resistance 150mOhm
Insulation Resistance 1000000000000Ohm
Contact Voltage(DC)-Max 200V
Throw Configuration SPDT
Contact Form SPDT (1 Form C)
Relay Type RF
Coil Resistance 1kOhm
Operate Time 0.5ms
Coil Voltage 12VDC
Coil Type Non Latching
Switching Voltage 200VAC 200VDC -Max
Coil Current 12mA
Must Operate Voltage 9VDC
Must Release Voltage 1VDC
Contact Voltage(AC)-Max 200V
Contact/Output Supply Type AC/DC
Coil Voltage (DC) 12V
Coil/Input Supply Type DC
PCB Hole Count 8
Input Switching Control Type Random
Dielectric Strength Between Coil and Contacts 1000 Vrms
Switching Current 500mA
Contact (DC) Max Power Rating R Load 10W@200VDC
Dimensions
Height 9.4mm
Width 20.57mm
Length - Termination 0.0034 inch
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
