09380122751
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Heavy Duty Connectors - Inserts, Modules
Description
INSERT FEMALE 6+6POS+1GND SCREW
PDF
/
Buying Options
Total Price: USD $144.06
Unit Price: USD $144.0648
≥1 USD $144.0648
≥10 USD $133.5004
≥100 USD $128.698592
≥500 USD $127.73816
Inventory: 51
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Housing Material Polycarbonate (PC)
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series Han-Com?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Insert
Number of Positions 6+6+Ground
Color Gray
Number of Rows 2
Gender Female
HTS Code 8536.69.80.00
Voltage - Rated DC 690V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Orientation Straight
Depth 51.3mm
Current Rating 100A
Contact Finish Silver
Termination Style Screw
Voltage - Rated AC 600V
Number of Contacts 12
Working Voltage 600V
Max Current Rating 100A
Size 24B
Dimensions
Length 111mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
