09330162616
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Heavy Duty Connectors - Inserts, Modules
Description
INSERT MALE 16POS+1GND PUSH IN
PDF
/
Buying Options
Total Price: USD $29.88
Unit Price: USD $29.876
≥1 USD $29.876
≥10 USD $26.1624
≥100 USD $25.031776
≥500 USD $24.224288
≥1000 USD $23.4168
≥3000 USD $22.124819
Inventory: 103
Minimum: 1
-
+
Technical Details
Technical
Size 16B
Test Current 16A
Wire/Cable Gauge 14 AWG
Max Current Rating 16A
Working Voltage 380V
Voltage - Rated AC 380V
Termination Style Push In
Contact Finish Silver
Current Rating 16A
Depth 33.4mm
Orientation Straight
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 500V
HTS Code 8536.69.80.00
Gender Male
Number of Rows 2
Color Gray
Number of Positions 16+Ground
Connector Type Insert
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Han? ES
Packaging Bulk
Operating Temperature -40°C~125°C
Dimensions
Length 84.5mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Ratings IP65
Physical
Housing Material Polycarbonate (PC)
Number of Pins 16
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 4 Weeks
