09330062701
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Heavy Duty Connectors - Inserts, Modules
Description
Han E Series Connector Insert, Female, 7 Way, 16A, 500 V
PDF
/
Buying Options
Total Price: USD $13.85
Unit Price: USD $13.8512
≥1 USD $13.8512
≥10 USD $12.2804
≥100 USD $11.808192
≥500 USD $11.335984
≥1000 USD $10.706168
≥3000 USD $9.761488
Inventory: 172
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP65
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Length 51mm
Technical
Size 6B
Test Current 16A
Durability 500 Cycles
Max Current Rating 16A
Body/Shell Style PLUG
Insulation Resistance 10000000000Ohm
Contact Resistance 1mOhm
Contact Style RND PIN-SKT
Working Voltage 380V
Operating Supply Voltage 600V
Body Breadth 1.339 inch
Reliability COMMERCIAL
Voltage - Rated AC 380V
Termination Style Screw
Contact Finish Silver
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 16A
Depth 34.6mm
Orientation Straight
Total Number of Contacts 6
Option GENERAL PURPOSE
Mixed Contacts YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 500V
Subcategory Headers and Edge Type Connectors
Gender Female
Number of Rows 2
Color Gray
Number of Positions 6+Ground
Connector Type Insert
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Han? E
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Mounting Option 2 LOCKING
Board Mounting Option MOUNTING FLANGE
Mounting Option 1 DETENT
Housing Material Polycarbonate (PC)
Number of Pins 6
Mounting Type CABLE
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 5 Weeks
