09320463001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Heavy Duty Connectors - Inserts, Modules
Description
INSERT MALE 46POS+1GND CRIMP
PDF
/
Buying Options
Total Price: USD $33.3
Unit Price: USD $33.2992
≥1 USD $33.2992
≥10 USD $29.16056
≥100 USD $27.900928
≥500 USD $27.000864
≥1000 USD $26.1008
≥3000 USD $24.660803
Inventory: 51
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Silver
Mounting Type CABLE
Number of Pins 46
Insulation Material Polycarbonate
Housing Material Polycarbonate (PC)
Mounting Option 1 M3
Mounting Option 2 LOCKING
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series Han? EE
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Insert without Contacts
Number of Positions 46+Ground
Color Gray
Number of Rows 4
Gender Male
Additional Feature ROHS COMPLIANT
HTS Code 8536.69.80.00
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 500V
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Contact Type Han?
Mixed Contacts YES
Option GENERAL PURPOSE
Total Number of Contacts 46
Orientation Straight
Depth 33.3mm
Current Rating 20A
Number of Conductors ONE
Reference Standard UL, CSA
Termination Style Crimp
Voltage - Rated AC 500V
Reliability COMMERCIAL
Body Breadth 1.339 inch
Working Voltage 500V
Contact Resistance 1mOhm
Insulation Resistance 1.01kOhm
Body/Shell Style RECEPTACLE
Max Current Rating 16A
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 20 AWG
Durability 500 Cycles
Size 24B
Dimensions
Length 111mm
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
