MFU0603FF02500P100

Vishay Beyschlag
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Circuit Protection / Fuses
Description FUSE BOARD MOUNT 2.5A 32VDC 0603
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.28688
≥100 USD $0.27456
≥500 USD $0.244816
≥1000 USD $0.228008
≥3000 USD $0.202646
Inventory: 1169
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount PCB, Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Terminal Shape WRAPAROUND
Number of Pins 2
Body Material Ceramic

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2008
Series MFU
Size / Dimension 0.061Lx0.033W x 0.018 H 1.55mmx0.85mmx0.45mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 37mOhm
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8536.10.00.40
Voltage - Rated DC 32V
Packing Method TAPE AND REEL
Depth 850μm
Reach Compliance Code unknown
Current Rating 2.5A
Case Code (Metric) 1608
Approval Agency UL
Body Length or Diameter 1.55mm
Case Code (Imperial) 0603
Body Breadth 0.85 mm
Physical Dimension 1.55mm x 0.85mm x 0.45mm
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.0157
DC Cold Resistance 0.037Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Fuse Current 2.5A

Dimensions

Height 457.2μm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
