MFU0402FF00800E100
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 800MA 32VDC 0402
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.52272
≥100 USD $0.506
≥500 USD $0.425568
Inventory: 111
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Terminal Shape WRAPAROUND
Technical
Operating Temperature -55°C~125°C
Packaging Cut Tape (CT)
Published 2011
Series MFU
Size / Dimension 0.040Lx0.020W x 0.013 H 1.00mmx0.50mmx0.32mm
JESD-609 Code e3
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Resistance 220mOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8536.10.00.40
Voltage - Rated DC 32V
Packing Method TAPE AND REEL
Reach Compliance Code unknown
Current Rating 800mA
Case Code (Metric) 1005
Approval Agency UL
Body Length or Diameter 1mm
Case Code (Imperial) 0402
Body Breadth 0.5 mm
Physical Dimension 1mm x 0.5mm x 0.32mm
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.0023
DC Cold Resistance 0.26Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Fuse Current 800mA
Dimensions
Height 330.2μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
