7023.0290
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
Fuse Miniature Fast Acting 10A 250V Holder Cartridge 6.3 X 32mm Ceramic Box
PDF
/
Inventory: 4456
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Holder
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Surface Mount NO
Terminal Shape END CAP
Number of Pins 2
Housing Material Ceramic
Weight 99.988768mg
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series A12BK
Size / Dimension 0.250Diax1.260L 6.35mmx32.00mm
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Clip
ECCN Code EAR99
Packing Method BOX
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency CSA, UL
Body Length or Diameter 6.35mm
Max Voltage Rating (AC) 250V
Power Dissipation 1.375W
Response Time Fast Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 10kA
Melting I2t 22
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Joule Integral-Nom 22 J
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
