7022.0850
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
Fuse Miniature Very Fast Acting 1A 660V Holder Cartridge 6.3 X 32mm Ceramic Box
PDF
/
Inventory: 2566
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 36 Weeks
Physical
Contact Plating Copper, Tin
Mounting Type Holder
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Surface Mount NO
Terminal Shape END CAP
Number of Pins 2
Housing Material Ceramic
Weight 3.000003g
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Series A12FA
Size / Dimension 0.250Diax1.252L 6.35mmx31.80mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Clip
ECCN Code EAR99
Terminal Finish TIN/TIN COPPER
Voltage - Rated 660V
Packing Method BOX
Current Rating 1A
Reference Standard UL
Voltage - Rated AC 660V
Approval Agency UR
Body Length or Diameter 6.35mm
Physical Dimension 6.35mm x 31.8mm
Max Voltage Rating (AC) 660V
Power Dissipation 4.45W
Response Time Fast Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 30kA
Melting I2t 0.41
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic SUPER FAST
Fuse Current 1A
Pre-arcing Time-Min 3600000ms
Dimensions
Body Height 31.8mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
