7022.0820
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
FUSE CERM 500MA 660VAC 3AB 3AG
PDF
/
Buying Options
Total Price: USD $4.54
Unit Price: USD $4.5408
≥1 USD $4.5408
≥10 USD $4.31992
≥100 USD $3.83064
≥500 USD $2.506909
Inventory: 72
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 31.8mm
Technical
Pre-arcing Time-Min 3600000ms
Blow Characteristic SUPER FAST
Circuit Protection Type ELECTRIC FUSE
Melting I2t 0.045
Breaking Capacity @ Rated Voltage 30kA
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Max Voltage Rating (AC) 660V
Physical Dimension 6.35mm x 31.8mm
Body Length or Diameter 6.35mm
Approval Agency UR
Voltage - Rated AC 660V
Reference Standard UL
Current Rating 500mA
Packing Method BOX
Voltage - Rated 660V
Composition Ceramic
Terminal Finish TIN/TIN COPPER
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Size / Dimension 0.250Diax1.252L 6.35mmx31.80mm
Series A12FA
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Weight 3.000003g
Number of Pins 2
Terminal Shape END CAP
Surface Mount NO
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Mounting Type Holder
Contact Plating Copper, Tin
Supply Chain
Factory Lead Time 28 Weeks
