3404.2326.11
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, Square End Block with Holder
Category Circuit Protection / Fuses
Description
Fuse Chip Slow Blow Acting 2A 125V SMD Solder Pad 12 X 5.2mm Thermoplastic Plastic Bag
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.7512
≥1 USD $1.7512
≥10 USD $1.46872
≥100 USD $1.1814
Inventory: 206
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 6mm
Technical
Pre-arcing Time-Min 5ms
Joule Integral-Nom 3 J
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
Melting I2t 3.58
Breaking Capacity @ Rated Voltage 100A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Slow Blow
Max Voltage Rating (DC) 125V
Power Dissipation 150mW
Max Voltage Rating (AC) 125V
Approval Agency CCC
Voltage - Rated AC 125V
Current Rating 2A
Depth 5.2mm
Packing Method BAG
Voltage - Rated DC 125V
HTS Code 8536.10.00.40
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.472Lx0.205W x 0.236 H 12.00mmx5.20mmx6.00mm
Series OMZ 125
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Weight 470.006744mg
Housing Material Thermoplastic
Number of Pins 2
Terminal Shape END CAP
Package / Case 2-SMD, Square End Block with Holder
Mounting Type Holder, Surface Mount
Mount Holder, Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
