3404.0116.24
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 2A 125VAC/VDC SMD
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.547876
≥1 USD $0.547876
≥10 USD $0.516869
≥100 USD $0.487611
≥500 USD $0.460004
≥1000 USD $0.433973
Inventory: 1145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 29 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, J-Lead
Terminal Shape WRAPAROUND
Number of Pins 2
Housing Material Thermoplastic
Weight 80.002354mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series OMT 125
Size / Dimension 0.291Lx0.122W x 0.102 H 7.40mmx3.10mmx2.60mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
HTS Code 8536.10.00.40
Voltage - Rated DC 125V
Packing Method BLISTER TAPE AND REEL
Depth 3.1mm
Current Rating 2A
Reference Standard CCC; CSA; UL
Voltage - Rated AC 125V
Approval Agency cULus
Body Length or Diameter 7.4mm
Max Voltage Rating (AC) 125V
Power Dissipation 150mW
Max Voltage Rating (DC) 125V
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Melting I2t 3.58
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 3 J
Pre-arcing Time-Min 5ms
Dimensions
Height 2.5908mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
