3404.0005.11
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 160MA 125VAC/VDC
PDF
/
Buying Options
Total Price: USD $0.71
Unit Price: USD $0.7128
≥1 USD $0.7128
≥10 USD $0.59488
≥100 USD $0.45408
≥500 USD $0.4158
Inventory: 436
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 29 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, J-Lead
Terminal Shape WRAPAROUND
Number of Pins 2
Weight 80.002354mg
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series OMF 125
Size / Dimension 0.291Lx0.122W x 0.102 H 7.40mmx3.10mmx2.60mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
HTS Code 8536.10.00.40
Voltage - Rated DC 125V
Packing Method BAG
Current Rating 160mA
Reference Standard CCC; CSA; CUL; UL
Voltage - Rated AC 125V
Approval Agency cURus
Body Length or Diameter 7.4mm
Body Breadth 3.1 mm
Max Voltage Rating (AC) 125V
Max Voltage Rating (DC) 125V
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Melting I2t 0.0018
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Pre-arcing Time-Min 10ms
Dimensions
Height 2.5908mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
