3403.0016.11
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Circuit Protection / Fuses
Description
Fuse Chip Fast Acting 1A 250V SMD Solder Pad 11 X 4.6mm Thermoplastic Plastic Bag
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.1
≥1 USD $1.1
≥10 USD $0.92136
≥100 USD $0.70312
≥500 USD $0.6446
Inventory: 505
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-SMD, J-Lead
Terminal Shape WRAPAROUND
Number of Pins 2
Weight 350.003213mg
Body Material Thermoplastic
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series OMF 250
Size / Dimension 0.433Lx0.181W x 0.154 H 11.00mmx4.60mmx3.90mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
HTS Code 8536.10.00.40
Voltage - Rated DC 250V
Packing Method BAG
Depth 4.6mm
Current Rating 1A
Reference Standard CCC; CSA; IEC; UL; UMF; VDE
Voltage - Rated AC 250V
Approval Agency cURus, VDE
Body Length or Diameter 11mm
Physical Dimension 11mm x 4.6mm x 3.9mm
Max Voltage Rating (AC) 250V
Current 1A
Power Dissipation 390mW
Max Voltage Rating (DC) 250V
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Melting I2t 0.23
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic VERY FAST
Pre-arcing Time-Min 1ms
Dimensions
Height 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
