3402.0017.24
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, J-Lead
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 5A 63VAC/VDC 2SMD
PDF
/
Buying Options
Total Price: USD $16.29
Unit Price: USD $16.28775
≥1 USD $16.28775
≥10 USD $13.3646
≥100 USD $12.9466
≥500 USD $12.52955
≥1000 USD $12.11155
Inventory: 1092
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 2.5908mm
Technical
Pre-arcing Time-Min 10ms
Joule Integral-Nom 2 J
Blow Characteristic VERY FAST
Circuit Protection Type ELECTRIC FUSE
Melting I2t 2.9
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Max Voltage Rating (DC) 63V
Power Dissipation 700mW
Max Voltage Rating (AC) 63V
Body Length or Diameter 7.4mm
Approval Agency cURus
Voltage - Rated AC 63V
Reference Standard CCC; CSA; UL
Current Rating 5A
Depth 3.1mm
Packing Method BLISTER TAPE AND REEL
Voltage - Rated DC 63V
HTS Code 8536.10.00.40
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.291Lx0.122W x 0.102 H 7.40mmx3.10mmx2.60mm
Series OMF 63
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 99.988768mg
Housing Material Thermoplastic
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case 2-SMD, J-Lead
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 29 Weeks
