0034.6946
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can, Vertical
Category Circuit Protection / Fuses
Description
Fuses with Leads (Through Hole) MXT 250 1.25A T 18.8
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5456
≥1 USD $0.5456
Inventory: 166
Minimum: 1
-
+
Technical Details
Technical
Packing Method BAG
Current Rating 1.25A
Reference Standard CCC; CSA; IEC; KTL; PSE; UL; VDE
Voltage - Rated AC 250V
Approval Agency CCC, cURus, KC, PSE/JET, VDE
Body Length or Diameter 8.5mm
Physical Dimension 8.5mm x 9mm
Max Voltage Rating (AC) 250V
Current 1.25A
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Wire/Cable Diameter 640 μm
Melting I2t 6.3
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 6 J
HTS Code 8536.10.00.40
Voltage - Rated 250V
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.335Dia x 0.335 H 8.50mmx8.50mm
Series MXT 250
Packaging Bulk
Operating Temperature -40°C~85°C
Dimensions
Height 8.509mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Body Material Thermoplastic
Weight 780.008779mg
Number of Pins 2
Terminal Shape PIN WIRE
Package / Case Radial, Can, Vertical
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 35 Weeks
