0001.2712.22
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 6.3A 250VAC 150VDC
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.379589
≥1 USD $1.379589
≥10 USD $1.301504
≥100 USD $1.22783
≥500 USD $1.158331
≥1000 USD $1.092766
Inventory: 3506
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Contact Plating Gold
Mounting Type Holder
Package / Case 5mm x 20mm
Surface Mount YES
Terminal Shape END CAP
Mounting Feature SURFACE MOUNT
Number of Pins 2
Housing Material Ceramic
Weight 1.000001g
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series SMD-SPT
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
HTS Code 8536.10.00.40
Voltage - Rated DC 150V
Packing Method TAPE AND REEL
Current Rating 6.3A
Reference Standard CSA; IEC; UL; VDE
Voltage - Rated AC 250V
Approval Agency CCC, cURus, ENEC
Max Voltage Rating (AC) 250V
Power Dissipation 4W
Max Voltage Rating (DC) 150V
Response Time Slow Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 1.5kA
Melting I2t 171
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Joule Integral-Nom 171 J
Pre-arcing Time-Min 10ms
Dimensions
Diameter 5.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
