80715000440
RoHS
RoHS compliant
RoHS compliantPackage Radial, Box
Category Circuit Protection / Fuses
Description
Fuses with Leads (Through Hole) 300V IEC TL 5A TE7
PDF
/
Buying Options
Total Price: USD $3.41
Unit Price: USD $3.4144
≥1 USD $3.4144
≥10 USD $3.30528
≥100 USD $3.19088
≥500 USD $2.506944
≥1000 USD $2.051192
≥3000 USD $1.994186
Inventory: 884
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Box
Terminal Shape PIN WIRE
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2011
Series TE7 807
Size / Dimension 0.488Lx0.252W x 0.362 H 12.40mmx6.40mmx9.20mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
Resistance 13.8mOhm
Terminal Finish Tin (Sn)
HTS Code 8536.10.00.40
Voltage - Rated DC 300V
Depth 6.4mm
Reach Compliance Code unknown
Current Rating 5A
Reference Standard CUL; KC; IEC; PSE; UL
Voltage - Rated AC 300V
Approval Agency cULus, KC, PSE/JET
Body Length or Diameter 12.4mm
Physical Dimension 12.4mm x 6.4mm x 9.2mm
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Melting I2t 625.4
DC Cold Resistance 0.0138Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Size TE7
Joule Integral-Nom 625 J
Dimensions
Height 9.1948mm
Compliance
RoHS Status ROHS3 Compliant
