80412000440
RoHS
RoHS compliant
RoHS compliantPackage Radial, Box
Category Circuit Protection / Fuses
Description
FUSE BOARD MOUNT 2A 250VAC RAD
PDF
/
Buying Options
Total Price: USD $3.1
Unit Price: USD $3.100605
≥1 USD $3.100605
≥10 USD $2.925097
≥100 USD $2.759528
≥500 USD $2.603328
≥1000 USD $2.455969
Inventory: 1152
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.1948mm
Technical
Fuse Current 2A
Joule Integral-Nom 80 J
Fuse Size TE7
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.0458Ohm
Melting I2t 80
Breaking Capacity @ Rated Voltage 150A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Slow Blow
Lead Length 4.3mm
Physical Dimension 12.4mm x 6.4mm x 9.8mm
Body Breadth 6.4 mm
Body Length or Diameter 12.4mm
Approval Agency CQC, KC, PSE, UL, VDE
Voltage - Rated AC 250V
Reference Standard CQC; IEC; KC; PSE; UMF; VDE
Current Rating 2A
Voltage - Rated DC 250V
HTS Code 8536.10.00.40
Terminal Finish Tin (Sn)
Resistance 45.8mOhm
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.488Lx0.252W x 0.362 H 12.40mmx6.40mmx9.20mm
Series 804
Published 2011
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Terminal Shape PIN WIRE
Package / Case Radial, Box
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
