39914000000
RoHS
RoHS compliant
RoHS compliantPackage Radial, Box
Category Circuit Protection / Fuses
Description
FUSE BRD MOUNT 4A 65VAC/VDC RAD
PDF
/
Inventory: 3635
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Box
Body Material Thermoplastic
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Box (TB)
Published 2006
Series TE5? 399
Size / Dimension 0.335Lx0.157W x 0.315 H 8.50mmx4.00mmx8.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Resistance 10mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Brown
Voltage - Rated 65V
Voltage - Rated DC 65V
Current Rating (Amps) 4A
Depth 4mm
Current Rating 4A
Voltage - Rated AC 65V
Approval Agency cULus
Power Dissipation 650mW
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 75
DC Cold Resistance 0.01Ohms
Dimensions
Height 8.001mm
Length 8.509mm
Width 3.9878mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
