39613150440
RoHS
RoHS compliant
RoHS compliantPackage Radial, Box
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 3.15A 125VAC RADIAL
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.11936
≥100 USD $1.0472
≥500 USD $0.866976
≥1000 USD $0.72248
≥3000 USD $0.704422
Inventory: 1073
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Box
Terminal Shape PIN WIRE
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2009
Series TE5? 396
Size / Dimension 0.335Lx0.157W x 0.315 H 8.50mmx4.00mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
Resistance 21.6mOhm
Terminal Finish Tin (Sn)
Color Brown
HTS Code 8536.10.00.40
Voltage - Rated DC 125V
Depth 4mm
Current Rating 3.15A
Reference Standard PSE; UL
Voltage - Rated AC 125V
Approval Agency cUL, PSE/JET, UL
Body Length or Diameter 8.5mm
Physical Dimension 8.5mm x 4mm x 8mm
Working Voltage 125V
Power Dissipation 350W
Response Time Slow Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Melting I2t 26.29
DC Cold Resistance 0.0216Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Fuse Size TE5
Joule Integral-Nom 22 J
Fuse Current 3.15A
Pre-arcing Rating 22 A2/s
Dimensions
Height 8.001mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
