39501600000
RoHS
RoHS compliant
RoHS compliantPackage Radial, Box
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 160MA 125VAC RADIAL
PDF
/
Buying Options
Total Price: USD $1.42
Unit Price: USD $1.419245
≥1 USD $1.419245
≥200 USD $0.550105
≥500 USD $0.530412
≥1400 USD $0.521221
Inventory: 1193
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Box
Terminal Shape PIN WIRE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Box (TB)
Published 2006
Series TE5? 395
Size / Dimension 0.335Lx0.157W x 0.315 H 8.50mmx4.00mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Radial
ECCN Code EAR99
Resistance 4.285Ohm
Terminal Finish Tin (Sn)
Color Brown
HTS Code 8536.10.00.40
Voltage - Rated DC 125V
Packing Method AMMO PACK; TAPE AND REEL
Depth 4mm
Current Rating 160mA
Reference Standard UL
Voltage - Rated AC 125V
Approval Agency cUL, UL
Body Length or Diameter 8.5mm
Physical Dimension 8.5mm x 4mm x 8mm
Lead Length 18.8mm
Power Dissipation 150mW
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 100A
Melting I2t 0.0037
DC Cold Resistance 4.285Ohm
Circuit Protection Type ELECTRIC FUSE
Fuse Size TE5
Fuse Current 160mA
Dimensions
Height 4mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
