37304000000
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can, Vertical
Category Circuit Protection / Fuses
Description
FUSE BOARD MNT 400MA 250VAC RAD
PDF
/
Inventory: 5493
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can, Vertical
Terminal Shape PIN WIRE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Box (TB)
Published 2014
Series TR5? 373
Size / Dimension 0.335Dia x 0.315 H 8.50mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
Resistance 220mOhm
Terminal Finish Tin (Sn)
Color Brown
HTS Code 8536.10.00.40
Voltage - Rated DC 250V
Packing Method AMMO PACK; TAPE AND REEL
Reach Compliance Code unknown
Current Rating 400mA
Reference Standard CSA; UL
Voltage - Rated AC 250V
Approval Agency CSA, cULus
Physical Dimension 8.5mm x 8mm
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.016
DC Cold Resistance 0.22Ohm
Circuit Protection Type ELECTRIC FUSE
Fuse Size TE5
Dimensions
Diameter 8.5mm
Height 8.001mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
