30315000421
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can, Vertical
Category Circuit Protection / Fuses
Description
FUSE BRD MNT 5A 125VAC 63VDC RAD
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.4848
≥1 USD $3.4848
≥10 USD $3.3616
≥100 USD $3.24192
≥500 USD $2.521376
≥1000 USD $2.113848
Inventory: 163
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Height 8.001mm
Diameter 6mm
Technical
DC Cold Resistance 0.0131Ohms
Melting I2t 1.5
Breaking Capacity @ Rated Voltage 50A
Fuse Type Board Mount (Cartridge Style Excluded)
Response Time Fast Blow
Power Dissipation 525mW
Working Voltage 125V
Approval Agency CSA, UL
Voltage - Rated AC 125V
Current Rating 5A
Current Rating (Amps) 5A
Voltage - Rated DC 63V
Color Black
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Resistance 13.1mOhm
Termination Radial
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.236Dia x 0.315 H 6.00mmx8.00mm
Series TR3? 303
Published 2009
Packaging Bulk
Operating Temperature -25°C~70°C
Physical
Package / Case Radial, Can, Vertical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
