20103150531P
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm w/Holder
Category Circuit Protection / Fuses
Description
Cartridge Fuses 250V .315A DIN M/TL PT 5X23
PDF
/
Inventory: 5714
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Holder
Package / Case 5mm x 20mm w/Holder
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -25°C~70°C
Packaging Tape & Reel (TR)
Published 2006
Series 201P
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Clip
ECCN Code EAR99
Additional Feature PRE-ARCING TIME: OPEN WITHIN 5 MS AT 1000% RATED CURRENT
Packing Method TAPE AND REEL
Reach Compliance Code unknown
Current Rating 315mA
Reference Standard CUL; UL
Voltage - Rated AC 250V
Approval Agency cULus
Body Length or Diameter 5.2mm
Physical Dimension 5.2mm x 20mm
Response Time Medium Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 80A
Melting I2t 0.16
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic MEDIUM TIME LAG
Dimensions
Body Height 20mm
Compliance
RoHS Status ROHS3 Compliant
