20100630021P
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
Cartridge Fuses 250V .063A DIN M/TL 5X20MM
PDF
/
Inventory: 8844
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Body Height 20mm
Technical
Fuse Current 63mA
Blow Characteristic MEDIUM TIME LAG
Circuit Protection Type ELECTRIC FUSE
Melting I2t 0.011
Breaking Capacity @ Rated Voltage 80A
Fuse Type Cartridge, Glass
Response Time Medium Blow
Physical Dimension 5.2mm x 20mm
Body Length or Diameter 5.2mm
Approval Agency cULus
Voltage - Rated AC 250V
Reference Standard CUL; UL
Current Rating 63mA
Reach Compliance Code unknown
Additional Feature PRE-ARCING TIME: OPEN WITHIN 5 MS AT 1000% RATED CURRENT
Resistance 100mOhm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.205Diax0.787L 5.20mmx20.00mm
Series 201P
Published 2006
Packaging Bulk
Operating Temperature -25°C~70°C
Physical
Terminal Shape END CAP
Surface Mount NO
Package / Case 5mm x 20mm
Mounting Type Holder
Supply Chain
Factory Lead Time 15 Weeks
