153.5395.6121
RoHS
RoHS compliant
RoHS compliantPackage Auto Link
Category Circuit Protection / Fuses
Description
Fuse 125A 32V Bolt 67.3 X 18.8 X 10.4mm
PDF
/
Buying Options
Total Price: USD $5.51
Unit Price: USD $5.5088
≥1 USD $5.5088
≥10 USD $5.31344
≥100 USD $5.1172
≥500 USD $3.93624
≥1000 USD $3.465
Inventory: 65
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Bolt
Mounting Type Bolt Mount
Package / Case Auto Link
Body Material Thermoplastic
Technical
Packaging Bulk
Series BF2
Size / Dimension 1.142Lx0.740W x 0.382 H 29.00mmx18.80mmx9.70mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Resistance 520μOhm
Color Green
Voltage - Rated 32V
Voltage - Rated DC 32V
Current Rating (Amps) 125A
Depth 18.8mm
Current Rating 125A
Voltage - Rated AC 32V
Response Time Slow Blow
Fuse Type Automotive
Breaking Capacity @ Rated Voltage 2kA
Melting I2t 118100
DC Cold Resistance 0.00052Ohms
Fuse Current 125A
Dimensions
Height 9.7028mm
Length 29.0068mm
Width 18.796mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
