0875.300MRET1P
RoHS
RoHS compliant
RoHS compliantPackage Cartridge, Non-Standard (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 300MA 250VAC AXIAL
PDF
/
Inventory: 3423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Cartridge, Non-Standard (Axial)
Terminal Shape PIN WIRE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 875
Size / Dimension 0.142Diax0.394L 3.60mmx10.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
Resistance 435mOhm
Reach Compliance Code unknown
Current Rating 300mA
Reference Standard CSA, UL
Voltage - Rated AC 250V
Approval Agency cULus
Body Length or Diameter 3.6mm
Physical Dimension 3.6mm x 10mm
Response Time Slow Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.043
DC Cold Resistance 0.435Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Trip Time or Delay 14400 s
Pre-arcing Rating 0.04 A2/s
Dimensions
Body Height 10mm
Compliance
RoHS Status ROHS3 Compliant
