0875.100MXEP
RoHS
RoHS compliant
RoHS compliantPackage Cartridge, Non-Standard (Axial)
Category Circuit Protection / Fuses
Description
FUSE CERAMIC 100MA 250VAC AXIAL
PDF
/
Inventory: 1547
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Cartridge, Non-Standard (Axial)
Terminal Shape PIN WIRE
Housing Material Ceramic
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 875
Size / Dimension 0.142Diax0.394L 3.60mmx10.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Axial
ECCN Code EAR99
Resistance 2.9Ohm
HTS Code 8536.10.00.40
Voltage - Rated DC 250V
Reach Compliance Code unknown
Current Rating 100mA
Reference Standard CSA; UL
Voltage - Rated AC 250V
Approval Agency cULus
Physical Dimension 3.6mm x 10mm
Response Time Slow Blow
Fuse Type Cartridge, Ceramic
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.0054
DC Cold Resistance 2.9Ohm
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Outside Diameter 3.6 mm
Fuse Current 100mA
Trip Time or Delay 14400 s
Dimensions
Body Height 10mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
