0673.800MXE
RoHS
/
Package Cartridge, Non-Standard (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 800MA 250VAC AXIAL
PDF
/
Inventory: 5240
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Body Height 11mm
Diameter 3.9mm
Technical
Trip Time or Delay 14400 s
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 0.112Ohm
Melting I2t 0.949
Breaking Capacity @ Rated Voltage 50A
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 3.9mm x 11mm
Approval Agency CSA, UL
Voltage - Rated AC 250V
Reference Standard CSA; UL
Current Rating 800mA
Reach Compliance Code unknown
Voltage - Rated DC 250V
HTS Code 8536.10.00.40
Resistance 112mOhm
ECCN Code EAR99
Termination Axial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.154Diax0.433L 3.90mmx11.00mm
Series 673
Packaging Bulk
Physical
Terminal Shape PIN WIRE
Package / Case Cartridge, Non-Standard (Axial)
Mounting Type Through Hole
Mount Through Hole
