0508001.MXP
RoHS
RoHS compliant
RoHS compliantPackage 3AB, 3AG, 1/4 x 1-1/4
Category Circuit Protection / Fuses
Description
Fuse Miniature Fast Acting 1A 1000V Holder Cartridge 6.3 X 32mm Ceramic Bulk CE/cULus
PDF
/
Buying Options
Total Price: USD $7.05
Unit Price: USD $7.0488
≥1 USD $7.0488
≥10 USD $6.79536
≥100 USD $6.54368
≥500 USD $5.0336
≥1000 USD $4.278648
≥3000 USD $4.02695
Inventory: 1192
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Body Height 31.75mm
Technical
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 1.58Ohm
Melting I2t 0.449
Breaking Capacity @ Rated Voltage 10kA
Fuse Type Cartridge, Ceramic
Response Time Fast Blow
Physical Dimension 6.35mm x 31.75mm
Body Length or Diameter 6.35mm
Approval Agency CE, cULus
Voltage - Rated AC 1kV
Reference Standard CE; CUL; UL
Current Rating 1A
Voltage - Rated DC 1kV
Resistance 1.58Ohm
ECCN Code EAR99
Termination Clip
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.248Diax1.260L 6.30mmx32.00mm
Series 508
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Body Material Ceramic
Number of Pins 2
Terminal Shape END CAP
Surface Mount NO
Package / Case 3AB, 3AG, 1/4 x 1-1/4
Mounting Type Holder
Supply Chain
Factory Lead Time 11 Weeks
