0498200.H
RoHS
RoHS compliant
RoHS compliantPackage Auto Link
Category Circuit Protection / Fuses
Description
FUSE AUTO 200A 32VDC AUTO LINK
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.646424
≥1 USD $2.646424
≥10 USD $2.496632
≥100 USD $2.355313
≥500 USD $2.221988
≥1000 USD $2.096215
Inventory: 1151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Bolt
Mounting Type Bolt Mount
Package / Case Auto Link
Terminal Shape TAB/BLADE
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series MIDI? 498
Size / Dimension 1.614Lx0.472W x 0.315 H 41.00mmx12.00mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Resistance 261μOhm
Terminal Finish Tin (Sn)
Color Violet
Voltage - Rated DC 32V
Reach Compliance Code unknown
Current Rating 200A
Reference Standard UL
Body Length or Diameter 16mm
Body Breadth 12 mm
Physical Dimension 16mm x 12mm x 8.3mm
Response Time Slow Blow
Fuse Type Automotive
Breaking Capacity @ Rated Voltage 1kA
Melting I2t 125000
DC Cold Resistance 0.000261Ohm
Circuit Protection Type ELECTRIC FUSE
Dimensions
Height 8.001mm
Compliance
RoHS Status ROHS3 Compliant
